Linear & Main Rotor Dampers

Arkwin’s linear dampers provide resistive forces to improve feel for aircraft control surfaces and dissipate energy from aerodynamic or mechanical loads. Our linear dampers endure millions of cycles under high side loads in dither conditions across the most demanding aerospace and defense environments. Designs can be self-contained with an integral reservoir or connected to the hydraulic system. Stepped damping curves can be developed to suit each application’s specific requirements.

Arkwin linear dampers and main rotor dampers are engineered for the unique demands of rotary airframes, where managing vibration, oscillation, and aerodynamic loads is critical to safe and reliable operation. Our dampers feature hydraulically balanced pistons, active and passive damping rate valves, and high side load tolerance — delivering precise resistive force as a function of piston velocity. Designs support single or stepped damping profiles, high frequency dithering, and electrical trim control. Self-contained and hydraulic system-integrated configurations are available across all designs.

Arkwin linear dampers are used across a range of rotary airframe applications including helicopter main rotor head dampers, pedal dampers and trim actuators, and landing gear damping.

Operational and Design Characteristics

• Single or stepped damping profiles
• High frequency dithering
• Electrical trim control and position override
• Hydraulically balanced piston with mechanical override
• Multiple operating fluid options
• Active and passive damping rate valves
• Bypass valves
• Multiple mounting options
• High side load tolerance
• External adjustment of damping force

Key Features

• Integral reservoirs
• Thermal expansion protection
• Fill indication
• Servicing provisions
• Self-contained or integral with hydraulic system
